Lyra
- Visual comfort
- CRI90 as standard
Lyra is a highly glare-free downlight for offices and other public environments. The luminaire has a metal frame and protection class II. Lyra can also be used in damp areas as it is IP44 from below. Lyra is available in three sizes 3, 6 and 8 with hole sizes 3 = 95-100mm, 6 = 165-180mm and 8 205-220mm. The luminaire is available in 3000K or 4000K and has an excellent color rendering CRI>90. The luminaire is available in variants with on/off or DALI. On/off is delivered with a free-standing strain relief actuator and 2.5m cord set. DALI can be connected as DALI or as impulse control/switch dim (for impulse control, all drivers must be of the same make). The DALI variant is supplied with a free-standing, strain-relieved DALI driver and 3.0m 5-wire cable.
Filter variants
| Downloads | ||||||
|---|---|---|---|---|---|---|
|
|
|
|||||
Description
E-number
Name
Photometric dataTechnical dataControlMaterials and environmental dataConnection and installationDimensions and weightProduct images |
