Tage Industry

Tage is a Swedish-made open industrial luminaire with a lot of light.
The luminaire is compact and low-built and is well suited as lighting for environments in industries, workshops and warehouses. Tage is mounted close to the ceiling (6mm groove) or on a cable with built-in cable bracket.
Tage is available in two lengths (1300 and 1600mm) and with four different beam angles, 30°, 60°, 90° and 120°.
The luminaire is available with on/off, DALI, BT PIR or BTDA, 4000K and with LED in one or two rows (2R).
Tage BT PIR has the possibility to forward DALI BUS with cable for up to 14 slave luminaires where all are controlled by the same PIR sensor. Communication to other sensors is wireless.
Tage BTDA works as “stand alone” and has no possibility to forward DALI BUS with cable, but all communication is wireless.

In BT-PIR/BTDA, the luminaires communicate with each other through a mesh network that relays information via the other luminaires.
This provides stable signal strength and is also suitable for difficult environments for radio signals, such as brick and concrete building materials.
Grouping and programming of the luminaires is done using Bluetooth/Blue tooth and the Exaktor Koolmesh app for iOS.

Tage is supplied as standard in zinc-coated sheet steel or white, but can be painted in any RAL color on request.

Connection is made at the ends without having to dismantle the optics or reflector, always with an override.
On/Off and BTDA have 5G2.5mm2, DALI and BT PIR have 5G2.5mm2 + 2×1.5mm2 for DALI.

On request, Tage is available with a different luminous flux, CRI90, other light color or with a quick switch.

The luminaire is manufactured in Värnamo.
